How to Test a Washing Machine Capacitor With a Multimeter in 7 Easy Steps (Complete Guide)

If your washing machine hums but won’t spin, or struggles to get a cycle started, a failing capacitor is one of the first things worth checking. This small component gives the motor the electrical boost it needs to start moving, and when it weakens or fails, the motor simply can’t do its job properly. Before assuming the worst. or calling a technician. testing the capacitor with a multimeter takes less than 15 minutes and can save you a significant repair bill. This guide explains how to test a washing machine capacitor with a multimeter safely and accurately before deciding whether replacement is necessary.

How to Test a Washing Machine Capacitor With a Multimeter Safely

What a Capacitor Actually Does Inside Your Washer

Most people don’t think about the capacitor until something goes wrong, and that’s completely understandable. It’s a small, unassuming cylindrical component tucked near the motor, easy to overlook during a visual inspection. But its role is anything but minor.

In single-phase AC motors. the type used in the vast majority of top-load and front-load washing machines. the motor needs a strong initial burst of electrical energy to overcome inertia and start spinning the drum. That’s where the start capacitor comes in. It stores a charge and releases it at just the right moment to give the motor that critical initial kick. Some machines also use a run capacitor, which stays active during the entire wash cycle to keep the motor running efficiently and prevent overheating. Understanding the capacitor’s role makes it easier to learn how to test a washing machine capacitor with a multimeter correctly.

When a capacitor starts to degrade, it can no longer store or release energy the way it’s supposed to. The motor gets a weaker push, works harder to compensate, and eventually either starts struggling or stops working altogether. Because capacitors wear down gradually, the symptoms often creep up slowly which is exactly why so many people assume the problem is the motor itself, when the real fix is a $10–$20 part

Warning Signs Your Washing Machine Capacitor Is Failing

There’s a recognizable pattern to how a bad capacitor behaves, and once you know what to look for, it becomes a reliable diagnostic clue. The most telling symptom is a motor that hums but doesn’t spin. you can hear the machine trying, but the drum won’t move. This happens because the motor is receiving power but can’t generate enough torque without a functioning capacitor delivering that startup boost. Many homeowners decide to test a washing machine capacitor with a multimeter after noticing these symptoms. Other signs to watch for.

• Sluggish or delayed startup. the drum takes several attempts before it finally kicks in
• Stops mid-cycle without an error code, leaving you with a drum full of wet laundry
• A faint burning smell near the motor compartment
• A visibly swollen or domed top on the capacitor itself. that bulging is caused by internal pressure from heat and electrolyte breakdown
• Frequent circuit breaker trips during startup. a shorted capacitor can draw excessive current as it tries to compensate for its own failure

If two or more of these symptoms are happening together, the capacitor is a very likely culprit and worth testing before anything else

Safety First: Discharge the Capacitor Before You Touch Anything

This is the step that gets skipped most often, and it’s the one that matters most. A capacitor stores electrical charge by design. that’s its entire purpose. and it doesn’t automatically discharge when you unplug the washing machine. Even hours after the machine has been powered off, a capacitor can still hold enough voltage to deliver a serious shock.

Before testing, follow these steps in order

1. Unplug the washing machine from the wall outlet
2. Wait at least five minutes before opening any panels
3. Locate the capacitor near the motor
4. Put on insulated rubber gloves and safety glasses
5. Use a 20,000-ohm resistor. touch one lead to each terminal simultaneously and hold for 5–10 seconds to safely bleed off the stored charge
6. Photograph the wiring connections before disconnecting anything
7. Remove the wires from the terminals and take the capacitor out of its bracket

What you should never do is short the terminals together with a screwdriver. That releases the stored energy in a single violent arc, which can damage the capacitor, ruin nearby wiring, and create a dangerous spark. The resistor method is slower by a few seconds. and far safer

How to Test a Washing Machine Capacitor With a Multimeter

Once the capacitor is safely discharged and removed, place it on a flat, non-conductive surface. wood or a rubber mat works well. Now you’re ready to test. This is the most accurate way to test a washing machine capacitor with a multimeter because it provides an actual microfarad reading.

Method 1: Capacitance Mode (Most Accurate)

If your multimeter has a capacitance mode. typically labeled CAP, µF, or marked with a symbol resembling two parallel lines with a curved line this is the method to use. It gives you an actual microfarad reading you can compare directly against the rating printed on the capacitor body.

How to do it:

1. Set the dial to capacitance mode
2. Insert the red probe into the VΩmA or CAP port, black probe into COM
3. Touch the red probe to the positive terminal, black to the negative
4. Wait a few seconds for the reading to stabilize
5. Compare the reading against the µF rating printed on the capacitor

Interpreting your results

Reading	What It Means	What to Do
Within rated µF range (±5–10%)	Capacitor is healthy	Look for another fault
10–20% below rated value	Capacitor is weakening	Replace soon
More than 20% below, or reads 0 µF	Capacitor has failed	Replace immediately
Reads OL (overload)	Capacitor is open/failed	Replace immediately

A 35 µF capacitor with ±5% tolerance, for example, should read between 33.25 and 36.75 µF. Anything significantly outside that window tells you the component is no longer doing its job reliably

Quick tip: If you’re getting erratic or inconsistent readings, the capacitor may not be fully discharged. Repeat the discharge step and test again.

Method 2: Resistance Mode (If You Don’t Have a Capacitance Setting)

Older or basic multimeters often skip the capacitance function, but you can still get a reliable diagnosis using the ohms setting. It won’t give you a precise µF reading, but it will tell you clearly whether the capacitor is shorted, open, or at least partially functional. You can still test a washing machine capacitor with a multimeter even if your meter does not include a capacitance setting.

How to do it:

1. Set the multimeter to its highest resistance range (2MΩ is ideal)
2. Touch the red probe to the positive terminal, black to the negative
3. Watch the display .a healthy capacitor will show resistance starting low and climbing steadily toward infinity (OL) as it charges from the multimeter’s internal battery
4. Swap the probes. the reading should start low again and climb back up

What the readings mean:

• Resistance climbs gradually toward OL → Capacitor is functional
• Reading stays at or near zero → Capacitor is internally shorted. replace it
• Reading jumps immediately to OL with no gradual rise → Capacitor is open — replace it

That slow, steady climb is the key indicator. It shows the capacitor is actually accepting and holding charge the way it should. No movement in either direction means it’s done

How to Replace a Washing Machine Capacitor

If your test confirms the capacitor has failed, replacement is one of the more straightforward appliance repairs you’ll encounter. Replacement should only be considered after you test a washing machine capacitor with a multimeter and confirm failure.

• Note the exact µF rating and voltage rating printed on the old capacitor (e.g., 35 µF / 450V)
• Purchase a matching replacement from an appliance parts supplier or a reputable online retailer. always match the µF value exactly, and meet or exceed the voltage rating
• Mount the new capacitor in the original bracket and reconnect the wires exactly as shown in your earlier photo
• Reassemble all panels, plug the machine back in, and run a full test cycle to confirm the repair

Capacitors are inexpensive and widely available for most major brands. In most cases, you’re looking at a total repair cost of under $25 and about 20–30 minutes of work from start to finish. Always test a washing machine capacitor with a multimeter before purchasing a replacement part.

When the Capacitor Isn’t the Problem

It’s worth saying clearly: testing the capacitor is a diagnostic step, not a guaranteed fix. If the capacitor tests healthy but the machine still hums without spinning, the motor windings may be burned out. If the machine doesn’t start at all, the lid switch or door latch sensor could be the real issue. Random mid-cycle stops that persist after a capacitor replacement often point to a thermal overload switch or a control board fault.

The capacitor is a smart first stop because it’s inexpensive, easy to test, and commonly responsible for these exact symptoms. But good troubleshooting means following the evidence. and sometimes the capacitor test simply rules out one possibility and points you clearly toward the next. Consider calling a technician if:

• The capacitor tests fine but the machine still won’t run
• You notice charred wiring or melted insulation inside the machine
• The machine burns through replacement capacitors repeatedly. this points to a deeper electrical issue
• You’re uncomfortable working around electrical components at any stage

Frequently Asked Questions

Can I test a washing machine capacitor without removing it?

Technically yes, but it’s not recommended. When the capacitor is still connected to the circuit, surrounding components can interfere with your multimeter readings and give you inaccurate results. For a reliable diagnosis, always disconnect at least one terminal wire before testing. It only takes a minute and makes the difference between a confident result and a misleading one.

How do I know if my multimeter can test a capacitor?

Look for a capacitance symbol on the dial. it usually looks like two parallel lines with a curved line, or it may simply be labeled CAP or µF. If you don’t see that symbol anywhere on the dial, your multimeter only measures resistance, which means you’ll need to use the ohms method instead. Either way, you can still get a useful reading. just not a precise microfarad value.

What happens if I don’t discharge the capacitor before testing?

Two things can go wrong. First, and most seriously, you risk a painful electrical shock. capacitors can hold dangerous voltage long after the machine is unplugged. Second, any residual charge left inside the capacitor will throw off your multimeter readings, making a partially failed capacitor appear healthy. Discharging first is both a safety requirement and a testing accuracy requirement.

My capacitor reads slightly below the rated µF value does it need replacing?

It depends on how far off the reading is. A drop of 5% or less is generally within normal tolerance and not a concern. If the reading is 10–20% below the rated value, the capacitor is weakening and likely headed toward failure. replacement makes sense at that point. Anything more than 20% below the rated value means the capacitor is no longer functioning reliably and should be replaced right away.

Can a bad capacitor damage the washing machine motor?

Yes, and this is an important point that many people overlook. A degraded capacitor forces the motor to work harder than it was designed to, generating excess heat in the motor windings over time. If a weak capacitor goes undetected and unaddressed for long enough, it can cause premature motor failure — turning a simple $15 fix into a much more expensive motor replacement. Catching and replacing a failing capacitor early is one of the best things you can do to extend your motor’s lifespan.

Where exactly is the capacitor located in a washing machine?

The location varies by machine type. In most top-load washers, the capacitor is mounted near the motor at the bottom of the unit, accessible by removing the back or front service panel. In front-load washers, it’s typically found behind the rear panel or near the motor housing at the base of the machine. If you’re unsure, check your owner’s manual. it will usually include a component diagram that shows exactly where to look for your specific model.

Final Thoughts

Knowing how to test a washing machine capacitor with a multimeter is one of those practical skills that pays for itself the first time you use it. You’ll avoid unnecessary service calls, make faster decisions about whether a repair is worth pursuing, and approach appliance problems with real diagnostic logic rather than guesswork. Most of the time,

when the symptoms line up and the capacitor fails the test, you’re looking at one of the simplest and most affordable fixes in appliance repair. A $15 part, a basic of careful work. that’s often all it takes to bring a washing machine back to life. Knowing how to test a washing machine capacitor with a multimeter allows you to make informed repair decisions and avoid unnecessary part replacements.
